Looking for an efficient and accurate solution for blind via holes in high-density PCB layouts? The HPTec 596 Series is a microvia drill with a conical outer diameter, specifically designed for mechanically drilled blind holes across one to three inner layers. Offering the highest hole quality and positioning accuracy, it’s a powerful alternative to laser drilling—especially on multispindle machines.
Key Features:
• Tapered geometry for blind microvias
• Exceptional hole wall quality and drill precision
• Reliable mechanical alternative to laser systems
• Max. drilling depth: 120 μm (Ø 0.12 mm) to 400 μm (Ø 0.40 mm)
• Available in sizes from Ø 0.12 mm to Ø 0.60 mm
• Custom diameters available on request
🔧 Made in Germany. Built for high-volume PCB manufacturing.
Engineered for HDI applications, the 596 Series offers a cost-efficient alternative to laser drilling—ideal where depth control and clean interconnects matter. Its stable geometry and tight tolerances minimize deviation across multilayer boards, even at high spindle speeds. Compatible with most BGA/HDI stackups, it’s built for production environments demanding speed, accuracy, and tool life.
